Demo unit – Full warranty – QUEST H35R Rangefinding Thermal Binocular 640×512 35 mm

All new for 2025, QUEST binoculars deliver a comfortable and intuitive viewing experience. Unlike thermal monoculars, the QUEST binoculars allow users to use both hands and both eyes while scanning – providing a smooth and comfortable feel, just like traditional daylight binoculars. A 12 μm ≤15mK 640×512 thermal sensor captures every detail, while the Reality+ image processing algorithm delivers a vivid picture to the 1920×1200 displays (full resolution per each eyepiece). Each display has a dedicated diopter and position adjustment.

QUEST binoculars also include an easy-to-use 1,000 yard laser rangefinder that can run in either single-firing or continuous modes to show target distance on the display. The combination of an internal USB-C rechargeable battery and an auxiliary IRB-2 (18650 style) rechargeable battery allows users to hot-swap the power source and keep running all night long. The QUEST is available with a 50 mm objective lens (model H50R) or a 35 mm germanium objective lens (H35R). Each comes with everything you would expect from high-end binoculars, including a comfortable and fully adjustable binocular harness.

Optics
Objective Focal Length
35mm

Detection Range
1970 Yards

Digital Magnification
8X

Vertical Angular Field of View
10°

Horizontal Angular Field of View
12.5°

Objective Lens Material
Germanium

Optical Magnification
3X

Objective F#
0.9

Objective Diameter
35mm

Display Type
AMOLED

Eye Relief
25mm

Diopter Range
-5 to +5

Focusing Mechanism
Manual Focus

Display Resolution
1920×1200

Features & Performance
Warranty
5 Years

Startup Time
<10 Seconds, Instant from Standby

Rangefinder
Integrated 1000 yd LRF

Color Palettes
White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian

Picture-in-Picture
Yes

Storage Capacity
64GB

Connector Output
Power/Data

User-Updatable Firmware
Yes

Mobile App
Yes

Run Time
5+

Power Source
USB-C External, 18650 Battery, Built-In Battery Pack

Stand-by Mode
Yes

Connector Type
USB-C

External Power Source
USB-C

Country of Manufacture
China

Wifi
Yes

Onboard Recording
Yes

Image Capture
Yes

Video Output
Yes

Environmental Specifications
Operating Temperature Range
-4°F~122°F

Ingress Protection
IP67

Physical
Housing Material
Polymer

Weight
24.69

Height
2.60

Width
5.43

Length
6.91

Sensor Specifications
Sensor Type
Nocpix 640

Device Technology
Thermal Imaging

Sensor Resolution
640×512

Sensor Pixel Size
12μm

Thermal Sensitivity
<15mk

Non-Uniformity Correction (NUC)
Manual, Automatic, Semi-Automatic

Sensor Frame Rate
60hz
