Nocpix – Slim – H35 – 2x Magnification – 640 Resolution Thermal Scope

SLIM
COMPACT MULTI-FUNCTION THERMAL OPTIC

The new SLIM series from Nocpix provides the best value and features in a compact optic. Focused on versatility and ease of use, SLIM models can be used as either a handheld monocular or a weapon sight. With the included proprietary quick-detach mounting system a hunter can quickly scan and then re-attach the optic to the rifle while maintaining zero. A magnesium alloy body and quiet, soft-touch buttons provide excellent ergonomics in both handheld and weapon-mounted configurations. The included IRB-2 batteries (flay-top 18650 style cell) are easy to swap–letting you stay out longer with the ability to charge through the optic using a magnetic cable. Generous eye relief and a 1024×768 AMOLED display provide a comfortable and highly detailed viewing and hunting experience.

• Ambidextrous one-handed design for easy use as a handheld monocular or weapon sight.
• Recoil-activated video automatically records footage before and after a shot.
• High-contrast 1024×768 AMOLED display provides increased clarity and detail.
• Quick-release dual-throw mount with a magnetic alignment aid provide fast and secure return-to-zero (1-MOA) weapon mounting.
• Uses common 18650 style rechargeable batteries.
• Available in high and standard-resolution models.
• Quick, secure charging via the magnetic charging port.

L35  / H35
Resolution 384×288 / 640×512
Pixel Size 12 μm
Frame Rate 50hz
Sensor Sensitivity ≤18 mK
Image Processing Reality+
Core Nocpix 384 Nocpix 640
Objective Lens 35 mm f/1.0
Magnification 3.5× / 2×
Digital Zoom 4×
Field of View 7.5° × 5.7° / 12.6° × 9.4°
Detection Range 1750 Yards
Display Type AMOLED
Display Resolution 1024×768
Color Palettes White Hot, Black Hot, Red Hot, Rainbow, Violet, Crimson, Viridian
Reticle Types 8 (6 Static, 1 Dynamic, 1 DIY)
Black Red, Black Green, White Red, White Green,
Black White, White Black, Crimson, Viridian
Reticle Colors
Mounting System Picatinny MIL-STD 1913 Rail
P.I.P Yes
Rangefinder None
Eye Relief 48 mm
Diopter Range -5 to +5
Onboard Recording Video, Recoil-activated Video, and Image
Onboard Storage 32 GB
Wireless Connectivity Video and Image via App
Data/Power Connector USB-C
Power Supply USB-C External, IRB-2 ×2 (4 Hours Each)
Start Up Time <10 Seconds, Instant from Standby
Size 8.50” × 2.99” × 1.81”
Weight 18.70 Oz
SENSOR
OPTICS
ELECTRONICS
PHYSICAL
ENVIRONMENTAL/WARRANTY
Warranty 5 Years
Housing Material Magnesium Alloy
Ingress Protection IP67
1000 G/s² (300 Win./7mm Mag)
Operation Temperature -4°F~122°F
Max. Recoil
