Demo – Full warranty – Nocpix ACE L35 Thermal Optic with Ocular Magnifier 3X 384×288 35mm

The ACE is built around the idea of combining leading user-requested features in a streamlined optic that balances advanced capability with ease-of-use in the field. Designed to feel like a traditional day optic, the ACE is compatible with bolt action or semi-automatic rifles using standard 30 mm mounts and rings. The combination of an internal USB-C charging battery and a removable 18650 style rechargeable battery allows users to hot-swap batteries in the field to run indefinitely. A 1-3x ocular magnifier provides optical magnification of the 2560×2560 round AMOLED display inside the eyepiece. The Vision+ system pairs this high-resolution display with a 18 mK NETD sensor for an incredibly detailed and precise image.

New for 2025, the ACE L35 offers a more affordable option in the ACE line for predator and hog hunters who don’t require a laser rangefinder or higher resolution sensor. Packing tremendous value, the ACE L35 retains all other features of ACE line of thermal rifle scopes.

A 1-3x optical ocular magnifier provides additional magnification of the display without any reticle shift or digital zoom.
High-contrast round 2560×2560 AMOLED display provides increased clarity and detail.
Simplified controls offer improved ergonomics and a better user experience in the field.
Uses common 18650 style rechargeable batteries.
Charge through the unit with a unique lock-out USB-C port design.

Key Product Specifications
Learn about the technical and environmental specifications of this optic. View the ACE L35 Data Sheet for even more detail.

Sensor
Nocpix 384 (384×288) 60 Hz

Objective Lens
35 mm F/0.9

NETD
≤18 mK

Magnification
Native/Optical: 3X Base, Digital: 4X

Data Sheet
ACE L35 Data Sheet

Product Manual
ACE Series Manual

Device Technology
Thermal Imaging

Pixel Size
12 μm

Display Resolution
AMOLED 2560×2560

Detection Range
1,970 Yards

Color Palettes
White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian

Reticles
8 (1 Dynamic, 6 Static, 1 DIY)

Rangefinder
None
