Hydra Mini

HS210M

One Thermal. Four Ways to Deploy.
The HYDRA-Mini HS210M is a 4-in-1 thermal optic that brings together Standalone, Handheld, Helmet-Mounted, and Clip-On capabilities in a single unit. Ultra-lightweight at 11.3 oz, it delivers exceptional thermal performance in a palm-sized package, seamlessly adapting to observation, hunting, and field operations.

Thermal Sensor Specification
Sensor Resolution: 256×192
Sensor Type: Uncooled Infrared Sensor
Sensor Frame Rate: 40 FPS
Pixel Size: 12×12
NETD: <18mK

Optical Specification
Objective Lens: 10mm
Base Magnification: 1x (1.4x)
Digital Zoom: 1x, 2x, 4x
Eye Relief: 65mm / 2.6 in

Display Specifications
Display Type: Micro-OLED
Display Resolution: 1024×768
Display Refresh Rate: 50Hz

Physical Specifications
Net Weight: 320 g / 11.3 oz
Total Weight: 550 g / 19.4 oz
Dimensions: 103x68x51 mm / 4.1×2.7x.2 in
Ingress Protection Rating: IP67
Recoil Rating: .50BMG / 800Gs

System Specifications
Storage: Built-In 32GB
Recording Format: 1024×768 @ 50 FPR
Connections: Wi-Fi / DNT Optics App

260908 HS210M
One Thermal. Four Ways to Deploy.
The HYDRA-Mini HS210M is a 4-in-1 thermal optic that brings together Standalone, Handheld, Helmet-Mounted, and Clip-On capabilities in a single unit. Ultra-lightweight at 11.3 oz, it delivers exceptional thermal performance in a palm-sized package, seamlessly adapting to observation, hunting, and field operations.

Standalone
Use the HS210M as a dedicated thermal scope for fast detection and engagement at close to medium ranges.

Handheld
Detach the HS210M for handheld thermal observation, scanning, and tracking.

Helmet-Mounted
Mount the HS210M to a helmet for hands-free thermal observation.
Required Setup
● A helmet with a compatible shroud and mount
● A dovetail binocular bridge compatible with Wilcox or KVC/RQE format
Helmet-Mounted Applications
1. Thermal for Detection, Night Vision for Aiming
2. Dual Thermal for Wider FOV and Depth Perception
3. Add a “Brain-Fusion” Thermal Layer to Your NVG View

Clip-On
Mount the HS210M in front of your day optic to add thermal capability while maintaining a true 1x thermal view.
Recommended Pairing: Day optics with a 1–2x base magnification for the best viewing experience.
Reticle: Use the day optic’s reticle for aiming and holdover while the HS210M provides the thermal image.
Mounting Height: The included QDF193 mount positions the HS210M 1.93 inches above the rail. Match your day optic to this height, or use compatible DNT quick detach mounts in 1.5-inch (QDM150, QDS150) or 1.7-inch (QDF170) heights.
Optical Zoom: In Clip-On mode, the HS210M provides a fixed 1x thermal view. To increase magnification, adjust the magnification of the day optic.

QDF193 Mount: Switch Setups in Seconds
The included QDF193 Dual Quick-Detach Flip-to-Side Mount makes switching between setups fast and effortless, with reliable zero retention after removal and reattachment. Move the HYDRA-Mini and mount together to another setup, or switch between helmet-mounted, handheld, and weapon-mounted configurations without removing screws.
Positioning the HYDRA-Mini 1.93″ above the rail, the QDF193 provides a tactical height that integrates seamlessly into quick-deploy setups.
[Watch the Full Guide]

AI-Powered ISR for Enhanced Thermal Imaging
Featuring a ≤18 mK NETD thermal sensor and always-on AI-powered Image Super Resolution (ISR), the HS210M delivers detailed thermal imaging and clear target identification in challenging conditions. With a wide FOV of 30.7×23 yd @ 100 yd and a 1x base magnification, it is built for fast detection and engagement at close to medium ranges, making it well suited for hog hunting and pest control.

Versatile Display and Aiming Options
With 4 thermal color palettes, 8 reticle styles, and 5 reticle color options, the HS210M offers flexible display and aiming choices for different environments and shooting scenarios. Picture-in-Picture (PiP) provides a 2x zoom window, enhancing target identification while keeping the broader scene in view.

Capture Every Highlight with Onboard Recording
Press the Record button for instant video and audio recording, or let Recoil Activated Video (RAV) capture the action automatically. With two rechargeable 18650 batteries, the HS210M provides up to 14 hours of total runtime (7 hours per battery), so you can stay in the field longer, worry-free.

Comfort, Control & Reliability
65 mm / 2.6″ Eye Relief
One-Shot Zeroing
IP67 Waterproof & Dustproof
.50 BMG Recoil Rated

DNT App: Smarter Tech, Richer Stories
With One Tap Connect, the DNT App connects to your scope to unlock more possibilities. In the field and afterward, view a live video feed, replay recordings to review each shot and refine your skills, or share the stories behind your hunts and adventures.
